BMS LFP 02S/10A(85079090) (JLGW)

The JLGW BMS LFP 02S/10A (85079090) is a battery management system designed for 2S (2 series) Lithium Iron Phosphate (LiFePO4) battery packs, supporting a continuous discharge current of 10A. It is suitable for medium-power applications such as energy storage, backup power, small electric vehicles, and DIY battery packs.​ Key Specifications Battery Type: LiFePO4 (LFP) Configuration: 2S (6.4V nominal, 7.3V max) Continuous Discharge: 10A Charging Current: Up to 8A Overcharge Detection: 3.75V ± 0.05V per cell Over-discharge Detection: 2.0V ± 0.1V per cell Short Circuit Protection: Yes (auto recovery enabled) Overcurrent Protection: Yes Temperature Protection: Optional (depends on version) Dimensions: Compact PCB, board-mounted
