BMS LFP 19S 60AMP SAME PORT W/P DALY (85079090)

The BMS LFP 19S 40AMP SMART CAN DALY is an advanced Battery Management System designed for 19 series (19S) Lithium Iron Phosphate (LFP) battery packs with a nominal voltage around 60V. Key Specifications: Battery Configuration: 19 cells in series (19S) Continuous Discharge Current: 40A Charge Current: 20A Charge Voltage: Approximately 69.35V Communication Interfaces: CAN Bus, UART for smart battery monitoring and integration with electric vehicle or energy management systems Protection Features: Over-voltage, under-voltage, over-current, short circuit, over-temperature, and under-temperature protections Cell Balancing: Integrated balancing to maintain uniform charge and protect battery life Build: Waterproof, dustproof, shockproof, and oxidation resistant with sealed injection-molded casing Cooling: Passive heat dissipation with an optional fan for thermal management
